Note that an adjusted radius will be used when existing geometry is supplemented ( Shift). The band of polygons that is created will have the edge length defined in this setting.
When in Draw Mode Polygon, polygons can be painted like with a brush. The finer the subdivision, the rounder the arc will be. Here you can enter the number of points the arc to be created should have. If the angle is smaller (or equal), the arc will come to rest exactly at the center angle of both polygon surfaces. If the angle between both edge polygons is larger than defined here, the arc can come to rest ON either of the polygon surfaces. This setting also applies to the aforementioned arc function. If this option is disabled, no elements will be snapped and no points will be melted.ĭepending on the angle defined, the arc will lie on the polygon surface or on the middle angle. Points that come to rest at the same location will be melted. If this option is enabled, a snapping function within the tool (only works with the current object) is activated with which points can be snapped to other points and edges to other edges - whereby the original edge will be rotated accordingly. Use Edge mode: paint (or click for both edge end points) edges that will be automatically connected to the previously created polygon.Use Point mode: click the four points of the first square and then click the two points of the adjoining edge, which will automatically be connected to the previously created polygon.If this option is enabled, a band of four-sided polygons will be created. Projection problems can occur in areas between empty space and an object surface. Note that the Polygon Snap option must be enabled in the Snap menu when painting on another object’s surface. The edge length will be adjusted automatically. The ,brush stroke’ can be snapped to or terminated at existing edges. As with any brush, the Polygon Pen’s radius ( Polygon Brush Radius) can be modified using the MMB.
If the Shift key is pressed while painting, a band of polygons can be created from an existing edge (the respective edge length will be used temporarily as the Polygon Brush Radius).
